All-In-One System with CD player, DAB/FM radio, HDMI ARC and HEOS® Built-in Streaming
Superb sound from an elegant, compact package. With a radio tuner, CD player, and HEOS® Built-in, plus HDMI ARC for TV connection, phono input, and audio pre-out, it’s the perfect audio hub for a small living space.
UNLOCK YOUR SMALLER SPACE
This mini system offers fantastic sound from an elegant, compact package. It the perfect audio companion for modest rooms.
SOPHISTICATED DESIGN
Compact, elegant design that fits beautifully in your space.
PERFECT FOR SMALL SPACES
With a built-in tuner and CD player, plus HDMI ARC for TV connection, it’s all you need.
PREMIUM LISTENING EXPERIENCE
Denon® RCD-N12DAB delivers high-fidelity sound with a premium DAC and supports the latest hi-res audio formats.
WIRELESS STREAMING
Stream music from nearly unlimited sources via HEOS Built-in, Airplay, or Bluetooth
HDMI ARC
Equipped with one HDMI ARC input, allowing a single cable connection with compatible television to elevate TV sound as well as direct volume control from the television or amplifier remote.
Quick Select buttons
With three Quick Select buttons accessible directly from the top of the product or the remote control, you can easily store your favourite internet radio stations or set for example volume level and input source by a press of one button, without the hassle of searching or the need of pressing several buttons.
HEOS Built-in streaming
HEOS® Built-in technology lets you enjoy music from Spotify, Amazon Music HD, Tidal, and more or play your local music files stored on a NAS. Smart devices can get connected via Bluetooth or Airplay easily. With additional HEOS Built-in components, like Denon Home speakers, play all your music in one room or many in perfect sync. Available music services vary by country. Easy control is guaranteed by the HEOS app.
Support for major voice control agents
Enjoy effortless voice control and total flexibility from the leading voice agents. Speak commands with Amazon Alexa, Google Assistant, or Apple Siri. Ask to play your favourite music, turn the volume up, skip to the next track, switch inputs and more. Switch between voice agents or pick a favourite to use—you’re in control. Functionality varies by voice agent.
Amazon Alexa voice control
Use your voice to stream your favourite music services through Alexa with HEOS Built-in. Ask Alexa to play music. Turn volume up or down, pause, mute, and play the next song—all with your voice. To start streaming with Alexa voice commands, open the Alexa app and select “Skills.” Add HEOS Home Entertainment to enable. Then, go to Smart Home in the Alexa app menu and choose Devices and Discover or say “Alexa, discover my devices.
Google Assistant voice control
Ask your Google Home, Googleapp or other devices with Google Assistant built-in to control content across your listening environment. Start music in the HEOS app, then ask your Google Assistant to control volume, play, pause, skip tracks and more. The “Works with the Google Assistant” feature is always improving.
AirPlay 2 and Apple Siri Voice Control
Stream audio from your favourite music services like Apple Music and Spotify or watch videos from services like YouTube and Netflix from any iPhone, iPad, Mac or Apple TV. Hear audio perfectly synced to your speakers from AirPlay 2 sources. AirPlay 2 also supports multiroom audio—wirelessly stream content to multiple AirPlay 2 compatible devices simultaneously with improved audio buffering to ensure smooth audio playback. AirPlay 2 provides control and grouping of compatible audio devices within the Apple Music or Home app. Use AirPlay 2 in-app or with your voice via Siri.
- CD player
- Playable frequency response: 10 Hz – 20 kHz
- Wow & flutter: Below measurable limits (± 0.001 %)
- Sampling frequency: 44.1 kHz
- Audio amplifier
- Rated output: 2-channel
- 65 W + 65 W (4 Ω/ohms, 1 kHz, THD + N 0.7 %)
- Dynamic power: 80 W + 80 W (4 Ω/ohms, 1 kHz, THD+N 10 %)
- Output terminals: Speaker: 4-16 Ω/ohms (impedance)
- Compatible with headphones/stereo headphones
- Tone control: SDB : +8 dB (100 Hz)
- Bass : ±10 dB (100 Hz)
- Treble : ±10 dB (10 kHz)
- AUX
- Input sensitivity/impedance: 200 mV/30 kΩ/kohms
- Frequency response: 10 Hz – 40 kHz (±3 dB)
- S/N Ratio (10 W, 4 Ω/ohms, IHF-A): 90 dB
- Total harmonic distortion (1 kHz, 5 W, 4 Ω/
- ohms): 0.1 %
- PHONO
- Input sensitivity/impedance: 2.5 mV/47 kΩ/kohms
- Frequency response: RIAA deviation (20 Hz – 20 kHz)
- S/N Ratio (IHF-A): 74 dB
- Tuner section [FM]
- Receiving Range: 87.50 MHz – 108.00 MHz
- Effective sensitivity: 1.2 μV / 75 Ω/ohms
- FM Channel separation: 42 dB (1 kHz)
- FM S/N ratio: Monaural : 70 dB
- Stereo : 70 dB
- FM THD+N (1 kHz): Monaural : 0.4 %
- Stereo : 0.4 %
- DAB tuner section
- Receiving Range: 174.928 (5A) – 239.200 (13F) MHz
- (BAND III)
- Sensitivity: – 85 dBm
- S/N ratio: 85 dB
- Wireless LAN section
- Network type (wireless LAN standard): Conforming to IEEE 802.11a/b/g/n/ac
- (Wi-Fi® compliant) z1
- Security: WEP 64 bit, WEP 128 bit
- WPA/WPA2-PSK (AES)
- WPA/WPA2-PSK (TKIP)
- WPA3-SAE (AES)
- Used frequency range: 2.4 GHz, 5 GHz
- Bluetooth section
- Communications system: Bluetooth Specification Version 5.0
- Transmission power: Bluetooth Specification Power Class 1
- Maximum communication range: Approx. 30 m in line of sight z2
- Used frequency range: 2.4 GHz
- Modulation scheme: FHSS (Frequency-Hopping Spread Spectrum)
- Supported profiles: Receiver function
- A2DP (Advanced Audio Distribution Profile) 1.2
- AVRCP (Audio Video Remote Control Profile) 1.3
- Transmitter function
- A2DP (Advanced Audio Distribution Profile) 1.2
- Corresponding codec: SBC
- Transmission range (A2DP): 20 Hz – 20,000 Hz
- Clock/Alarm/Sleep
- Clock type: Power line frequency synchronized method (Within ±60 seconds per month)
- Alarm: Once alarm/Everyday alarm: One system each
- Sleep: Sleep timer: Max. 90 minutes
- General
- Operating temperature: +5 ℃ – +35 ℃
- Power supply: AC 230 V, 50/60 Hz
- Power consumption: 55 W
- Maximum Dimensions (W x D x H) in mm 280 x 305 x 108
- Weight in kg 3.4
